型号：mATX-C232A |
|
|
CPU |
Intel® Xeon®/ 6th and 7th Generation CoreTM i3/i5/i7 CPU, LGA1151 |
|
芯片组 |
Intel® C232 Chipset, TDP 6W |
|
内存 |
Up to 32 GB DDR4 2133/1866 MHz, 4*DIMM, Support ECC |
|
存储 |
6*SATA 3.0, 4* SATA 2.0 |
|
扩展接口 |
2*PCI-E 8X, 1*PCI-E 4X, 1*PCI, 1*Mini-PCIe |
|
BIOS |
AMI UEFI BIOS |
|
OS |
Windows 7/8/10, Server 2008/2012, Linux |
|
I/O 接口 |
|
|
串口 |
2*RS232 |
|
USB |
6*USB 3.0, 2*USB 2.0 (4*on rear I/O, 4*header) |
|
网络 |
2*Intel® PCI-E LAN for 1000Mbps |
|
声卡 |
Null |
|
PS/2 |
Null |
|
并口 |
Null |
|
GPIO |
8 programmable GPIO |
|
Feature Interface |
Null |
|
显示 |
|
|
显示接口 |
1*VGA: max resolution up to 1920*1080@60Hz |
|
多显 |
Single |
|
使用环境 |
|
|
板型 |
Micro-ATX, 244*244mm |
|
电源 |
ATX PSU |
|
温度 |
Operation: 0℃~60℃, Storage: -25℃~75℃ |
|
温度 |
Operation: 10%~90%, Storage: 5%~95%, non-condensing |
